Unified Chassis
Indoor Unit :

ASSA18FUTA / ASSA24FUTA / ASSA30FUTA / ASSA36FUTB
ASSA18UUTA / ASSA24UUTA / ASSA30UUTA / ASSA36UUTB


Model
230V Single-Phase | |
---|---|
ASSA18FUTAZ | |
ASSA18UUTAZ | |
ASSA24FUTAZ | |
ASSA24UUTAZ | |
ASSA30FUTAZ | |
ASSA30UUTAZ | |
ASSA36FUTBZ | |
ASSA36UUTBZ |
Outdoor Unit :

AOSA18FUTAH
AOSA18UUTAH

AOSA24FUTAH
AOSA24UUTAH

AOSA30FUTAS
AOSA30UUTAS

AOSA36FUTBS
AOSA36UUTBS
Feature
Powerful airflow
Long-reach airflow up to 25m is provided by optimized airflow design.
25m Powerful mode (30 / 36 class)

Faster cooling
New models accelerate to cool air quicker to reach the setting temperature in the entire room than the current models do.

New Technology
Optimized airflow design
airflow 38%UP!*
- *
- 36 class

[1]

- Dual suction design Large airflow volume from dual suction
[2]

- New long cross-flow fan
[3]

- High output DC fan motor
6 Speed control
6-Speed fan control with added Powerful Cooling mode is provided.
Airflow 38*% up than current model (high mode)

- *
- 36 class
- *
- One touch powerful cooling mode: Continuous operation for 30 minutes at maximum air volume
Powerful cooling
Higher cooling capacity is achieved at the ambient temperature of 52°C condition.

High energy saving
Higher EER is achieved by the new technologies and new refrigerant.
- *
- 18 class
